Where projects demand extended reach and precision over water channels, banks, or deep pits, the R245LR SMART X PLUS steps up with its long-reach architecture and stability-focused build. It retains the proven Hyundai powertrain while stretching operational capability through its extended boom-arm geometry. Contractors gain the advantage of wide-area coverage without repositioning, improving productivity in canal cleaning, desilting, and river-maintenance tasks.
SMART X PLUS refinements bring an improved electro-hydraulic flow system for smoother long-reach control and enhanced operator cluster with custom modes for fine-tuned responsiveness. Structural upgrades—heavier-gauge boom sections, reinforced arm plates, and optimized counterweight—ensure balance and durability during far-reach digging.
For municipal bodies, irrigation departments, and contractors handling water-body maintenance or slope profiling, the R245LR delivers predictable output with extended working envelopes that conventional 20–22-ton machines cannot match.
| Equipment | UNIT | R245LR Smart X PLUS |
|---|---|---|
| Engine Model | Cummins 6BT5.9C | |
| Gross Power (HP) | HP @ rpm | 140 @ 2000 |
| Operating Weight | Kgs | 24500 |
| Bucket Range | Cu.M | 0.52 |
| Swing speed | rpm | 11 |
| Travel speed, high/ low | km/hr | 5.3/3.4 |
| Max. digging reach on ground | mm | 15163 |
| Max. digging Depth | mm | 11754 |
| Tail swing radius | mm | 2830 |
| Bucket digging force | kgf. | 10300 |
| Arm crowd force | kgf. | 5500 |
| Bucket Capacity | Cu.M | 0.52GP |
The digital cluster displays key machine information like oil temperature, coolant temperature, and other vital statistics. Optimized performance is achieved by letting operator to choose between three power modes and two work modes and two User Modes.
When a component is unoperational, a control lever stroke maintains high standby pressure of hydraulic oil in the hydraulic hoses rather than sending it back to the main control valve. It not only results in faster response time of the hydraulic component, but also fuel savings.
Higher hydraulic oil flow to various components results in shorter cycle times and thus more profitability.
The Hydraulics and attachments are designed to offer high digging forces.
The sensors in this kit monitor undue loads and send signals to the Main Control Valve to cut down unnecessary fuel consumption. It helps to increase fuel efficiency.
The auto-piloted swing priority increases hydraulic oil flow to swing circuit in combined operation, which leads to faster swing cycle for more productivity & profitability.
The R245LR SMART X PLUS Series excavator is equipped with features designed to enhance operational convenience. A removable floor mat for easy cleaning and improved maintenance, helping to keep the operator area neat and well-maintained. The integrated Bluetooth FM radio provides added functionality for communication and entertainment. LED lamps offer improved visibility in low-light conditions, supporting safer and more efficient operations. Additionally, the fuel filler pump simplifies the refueling process, reducing downtime on site.
This smart feature keeps a record of scheduled time interval for each maintenance area. This feature ensures maintenance of the machine by keeping the operator updated at all the times.
New forged ring body in lower frame enhances the durability, structural integrity and increases the machine life.
Side Member reinforcement protects the idler from any damage in tough terrains. A heavy-duty track shoe provides better stability and durability on harsh terrains.
Control link is casted in one-piece design. The bucket linkages are reinforced to ensure high durability and high digging forces.
A wide track shoe of 800 mm provides better stability while working on heavy loads or in harsh terrains. It also helps to increase operator convenience and reduce fatigue.
This feature monitors coolant temperature and automatically lowers engine speed if it overheats, thereby preventing premature failure of the machine.
The emergency shutdown switch enhances operator safety by providing a quick and reliable way to instantly stop the machine during emergency situations.
Beacon lamp enhances site safety by providing high-visibility warning signals during machine operation.
Swing lock enhances safety while working on slopes, gradients.
